EN - 21
EN
USB-C POWER CABLE:
• Never place the USB-C power cable onto hot surfaces and do not leave it hanging over
the edge of a table or worktop. If someone, e.g. a child, brushes against the cable or
tugs at it, the appliance might overturn or fall down and it might result in a serious injury!
• The USB-C power cable must not be damaged by sharp or hot objects or open flame, it
must not be submerged in water or bent over sharp edges.
For trouble-free operation of the vacuum cleaner, please use the
tested micro-filters recommended by the producer.
II. EQUIPMENT AND ACCESSORIES
A – vacuum cleaner
A1 – ON/OFF button
A2 – suction power switch
A3 – light signalling
A4 – handle
A5 – tipping brush
A6 – USB-C charging socket
B – dust container
B1 – dust container lock button
B2 – HEPA filter
B3 – separator
B4 – foam filter
B5 – hinged bottom
B6 – bottom lock button
C – floor nozzle with rotation brush
C1 – floor nozzle lock button
C2 – removable rotary brush
C3 – brush lock
C4 – LEDs illuminating the space in
front of the vacuum cleaner
D – metal suction tube / crevice nozzle
D1 – tube lock button
E – USB power cable
F – cleaning tool
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories.
Remove all possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1. Select
appropriate accessories (Fig. 5) depending on the required use. For disassembly, proceed
the other way round and release the locks.
CHARGING THE ACCUMULATOR
Turn the vacuum cleaner off prior to charging! Select a suitable power supply (power
adaptor), connect the USB power cable E to the vacuum cleaner in the power socket A5 and to
the power supply and then to the electrical supply. The accumulator has to be charged at least
for 4 hours prior to the first use. After that, the standard charging time is approx. 3 hours.
The charging status and progress is indicated by the A3 light signal.
