MOUNTING THE PLASTIC BRACKET TO THE WALL
Mount the plastic bracket I to the wall using the fastener included J, K or a similar fastener
provided by you.
Caution
– Make sure that the el. socket is close to the mounted plastic bracket.
– Make sure that no electricity, telephone or water lines etc. are routed under the
plaster near the area where the plastic bracket is mounted to the wall.
IV. USE OF VACUUM CLEANER (Fig. 4 - 5)
Let the vacuum cleaner charge sufficiently prior to using.
CONTROL
ON / OFF button (A1)
- press the button to switch the vacuum cleaner on,
- press the button to switch the vacuum cleaner off.
Button " " - suction power adjustment (B1)
- touch short the button to increase/reduce the suction power (suction power is indicated by
lighting LEDs B2 (MIN / ECO / MAX).
- MIN / = low- mode,
- ECO / = economic mode,
- MAX / = high mode.
Notes: The vacuum cleaner is set to ECO suction power when switched on.
Caution
Floor nozzle
D
have electronic protection against rotation brush blocking. If the rotation
brush has been blocked during operation, observe the following instructions.
– If the floor nozzle rotation brush
D
has been blocked, LEDs D
2
go off and the brush
stops rotating. Switch off the device and remove the cause, then the device can be
switched on again.
Full dust container and HEPA filter signaling
If the red light on the A2 control panel lights up permanently, the filter system must be
cleaned even if the container is not yet full. Do not take into account the occasional
illumination of the indicator light during vacuuming. If the suction opening/airways become
blocked, the overload protection switches off the motor (valid when the suction power is set
to MIN). If this situation occurs, switch off the vacuum cleaner and remove the cause of the
blockage and then you can switch the vacuum cleaner on again.
V. CLEANING AND MAINTENANCE
DUST CONTAINER (A4)
If you find out that the suction performance of the vacuum cleaner A is reduced, make sure
that the dust container is not full and if necessary, empty it (follow the procedure indicated
in Fig. 6). Put the container above a dust bit and press button A6; thus you will lift off bottom
and throw the dust in common municipal waste. Snap the bottom shut to secure it in the
opposite direction.
28
EN
/ 58
