EN - 23
EN
II. EQUIPMENT AND ACCESSORIES (Fig. 1-6)
A – vacuum cleaner
A1 – ON/OFF switch
A2 – upper section with drive unit
A3 – lower section with dirt container
A4 – suction vent
A5 – exhaust orifice
A6 – upper section locking mechanism
A7 – wound cable holder
A8 – accessories holder
A9 – handle (3x)
A10 – swivel casters
A11 – chamber with safety float
A12 – HEPA filter
A13 – nut
A14 – dust bag
A15 – foam filter
A16 – power cord
B – accessories
B1 – parquet nozzle
B1a – combined slats
B1b – rubber slats
B2 – crevice nozzle
B3 – upholstery nozzle
B4 – suction hose
B5 – mechanic suction power control
B6 – telescopic suction tube
B7 – telescopic suction tube locking
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories.
Remove all possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1-5. Install
swivel casters A10 (Fig. 6) before the first use. Choose appropriate accessories as required
(B1-B3) (Fig. 7). The accessories (B1-B3) can be connected either to the telescopic suction
tube B6 or directly to the suction hose B4. Parquet cleaning nozzle B1 has replaceable slats
B1a and B1b. Please refer to Fig. 5. for changing the slats.
IV. USE OF VACUUM CLEANER
Once assembled, connect the A16 power cord plug to the mains.
CONTROL
ON/OFF switch (A1) - vacuum cleaner ON/OFF switch
VACUUMING SOLID DIRT
Use accessories B1+B1a, B2, B3, B4, B6 for removing solid dirt. If removing dry dirt,
you can insert dust bag A14 or lead the dirt directly to the dirt container (no dust bag).
If removing solid dirt, have always the HEPA filter installed.
VACUUMING LIQUID DIRT
Note
Prior to removing liquid dirt, take out dust bag A14 and also HEPA filter, thus
avoiding damage of these components by moisture!
