II. EQUIPMENT AND ACCESSORIES
A – vacuum cleaner (Fig. 1)
A1 – ON/OFF switch
A2 – Upper section with drive unit
A3 – Lower section with dirt container
A4 – suction vent
A5 – Exhaust orifice
A6 – Upper section locking mechanism
A7 – Wound cable holder
A8 – Accessories holder
A9 – handle (3x)
A10 – Swivel casters
A11 – Chamber with safety float
A12– HEPA filter
A13 – nut
A14 – Permanent plastic dust bag
A15 – power cord
B – accessories (Fig. 1, 2)
B1 – parquet nozzle
B1a – Brush slats
B1b – Rubber slats
B2 – brush
B3 – crevice nozzle
B4 – suction hose
B5 – Mechanic suction power control
B6 – Plastic suction tube (2x)
B7 – Storage holder
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories.
Remove all possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1. Install
swivel casters A10 (Fig. 3) before the first use. Choose appropriate accessories as
required (B1-B3) (Fig. 6). The accessories (B1-B3) can be connected either to plastic
suction tubes B6 or directly to suction hose B4. Parquet cleaning nozzle B1 has
replaceable slats B1a and B1b. Please refer to Fig. 4. for changing the slats.
IV. USE OF VACUUM CLEANER
CONTROL
ON/OFF switch (A1) -
vacuum cleaner ON/OFF switch
VACUUMING SOLID DIRT
Use accessories B1+B1a, B2, B3, B4, B6 for removing solid dirt. If removing dry dirt,
you can insert dust bag A14 or lead the dirt directly to the dirt container (no dust bag). If
removing solid dirt, have always the HEPA filter installed.
VACUUMING LIQUID DIRT
Note
Prior to removing liquid dirt, take out dust bag A14 and also HEPA filter, thus
avoiding damage of these components by moisture!
Use accessories B1+B1b, B3, B4, B6 for removing liquid dirt.
BLOWING AIR FUNCTION
In addition to standard vacuum cleaning, the unit also features blowing air function. If you
want to use this function, connect hose B4 to exhaust orifice A5. Where required, plastic
suction tube B6 can also be connected to the suction hose. This function can be used for
blowing off dust and/or other particles on the surface/floor.
GB
21 / 42
