EN
EN - 57
USING THE CONTROL PANEL
1
2
3
A
B
D
E
C
1.1 LED DISPLAY
1 - Temperature of Fridge Comparment
2 - Temperature of Freezer Comparment
3 - Temperature of Convertible Comparment
1.2 KEY OPERATION
A - Fridge Temp.Setting
B - Convertible Zone Temp.Setting
C - Freezer Temp. Setting
D - Mode Setting (ECO, Holiday, Super freezing)
E - Locking/Unlocking Setting
2.0 OPERATING CONDITION
a. The control panel is 100% lit up for 3 seconds, which
operates exactly as per the setting (mode and temperature)
before the powero. The system will be automatically locked 25 seconds after the
last key operation. After locking, the light of the panel would be out 120 seconds
after the last key operation.
b. The Fridge/Freezer/Convertible Zone temperature will be showed Separately by
setting each zone temperature.
2.1 DISPLAY
2.1.1 The panel will be lit up for 2 minutes once the door of fridge compartment or freezer
compartment is opened. (one door signal is sensed at a time).
2.1.2 The panel will be lit up by any key operation whereas the light would be out 2 minutes
after the last operation.
2.1.3 Display during normal operation
Temperature Display of the Fridge Compartment:
Indicating the temperature of the current setting.
Temperature Display of the Freezer Compartment:
Indicating the temperature of the current setting.
Temperature Display of the Convertible Compartment:
Indicating the temperature of the current setting.
3.0 ILLUSTION OF THE KEY
Press Button
Short beep after per press button
All buttons will only valid under unlock mode.
3.1 A - Temperature Control of the Fridge Compartment
a. Temperature Control of the Fridge Compartment:
This key is workable both in User Dened Mode as well as Super Mode. After
entering the temperature control of the fridge compartment, this key ashes. By
touching the key consecutively, the temperature would change in a circle of “2°C,
3°C, 4°C, 5°C, 6°C, 7°C, 8°C, -- (OFF)”, after which 5-second ashing means the
selection of temperature is settled.
