EN
EN - 104
Dishwasher installation steps
1. Affix the condensation strip under the work surface of cabinet.
Please ensure the condensation strip is flush with edge of work surface.
2. Connect the inlet hose to the cold water supply.
3. Connect the drain hose.
4. Connect the power cord.
5. Place the dishwasher into position.
6.
Install the furniture door to the outer door of the dishwasher using the brackets
provided. Refer to the template for positioning of the brackets.
7. Adjust the tension of the door springs (Figure 7) by using an phillips screwdriver
turning in a clockwise motion to tighten the left and right door springs. Failure to do
this could cause damage to your dishwasher.
8. Level the dishwasher. The rear food can be adjusted from the front of the dishwasher
by turning the screw in the middle of the base of dishwasher use an phillips
screwdriver (Figure 8A). To adjust the front feet, use a flat screw driver and turn the
front feet until the dishwasher is level (Figure 8B).
9. The dishwasher must be secured in place. There are two ways to do this:
A. Normal work surface:Put the installation hook into the slot of the side plane and
secure it to the work surface with the wood screws (point 9A).
B. Marble or granite work top:Fix the side with Screw. (point 9B).
7
5
1
6
2,3,4
9
8
A
B
A
B
