Energy consumption values
Programmes Load (kg)
Washing
machine
Spin speed
Approximate amount
of residual moisture
Energy
consumption
values (kWh)
ECO*
8 1000 60% 1,97
Easy iron
8 1000 60% 1,50
Ready-to-wear
4 800 40% 0,75
*The “Cottons Eco programme” is the standard drying cycle to which the
information on the label refers. This programme is suitable for drying normally
damp cotton textiles. It is the most efficient programme in terms of combined
energy consumption for cotton.
Technical features
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 59,9 cm
Capacity (max.) 8 kg **
Net weight (± %10) 44 kg
Voltage
See type label
Rated power input
Model code
*Min. height.: Height with adjustable feet not used. Max. height.: Height with adjustable
feet in maximum extension.
**Weight of dry laundry before washing.
cleaning and maintenance
The service life of the appliance increases and frequently encountered problems are
reduced if it is properly cleaned at regular intervals.
WARNING! Unplug the appliance from the socket
before cleaning or servicing it.
Cleaning the lint lter
The lint and fibres that are released from the laundry into the air during the drying cycle
are collected by the “lint filter”. These particles usually form as a result of wear and
washing.
Always clean the filter after each drying cycle and
when the indicator lamp is lit.
To clean the filter:
1. Open the dryer door.
2. Lift the lint filter out of its housing (fig.3).
3. Open the filter by pressing the tab (see fig.4) to separate the two ends (fig.5).
4. Remove lint, fibres and cotton residue by hand or with a soft cloth (fig.6).
5. Close the lint filter and put it back into its housing.
NOTE: Over time, the surface of the filter may become clogged after use. In this case,
wash the filter on both sides with water.
IMPORTANT: Make sure that the filter mesh is dry before putting it back in its
housing.
Fig. 5
Fig. 6
Fig. 3
Fig. 4
50
51
EN
