• The appliance’s energy consumption and effi cient operation are affected by the room
temperature.
• The appliance must be installed in such a way that the power point is accessible.
• After installing it, make sure that it is not resting on its power cord.
Before plugging the appliance into
the mains socket for the fi rst time,
please let the appliance rest for two
hours if the appliance was transported
in an upright position, or 24 hours if the appliance
was transported in the horizontal position. This is
to allow the refrigerant gas to go back down into
the compressor. Failure to comply with this
waiting period may damage the compressor.
Climate class
Only install the appliance in a location where the room temperature matches the climate
class for which it was designed (see table below).
The climate class is on the rating plate located inside the appliance.
The table below shows the correct room temperature for each climate class:
Climate class Room temperature
SN from +10 to +32 °C
N from +16 to +32 °C
ST from +16 to +38 °C
T from +16 to +43 °C
Your refrigerator ERMVE190-90hov1 is rated "SN/N/ST". If the room temperature is below or
above the rated room temperature, the performance of your refrigerator may be affected, and your
food may spoil.
Suffi cient ventilation
• The refrigerator is not intended to be used as a built-in appliance and ideally it should not be
positioned directly under a cabinet.
• Make sure that air can circulate freely around the appliance to ensure that it can work properly
(see fi gure below).
• The space above the refrigerator and to the rear should be more than 50 mm and at least 50mm
on both sides to facilitate heat dissipation.
• Make sure you leave enough space for the door to open.
• If your appliance is to be installed next to another refrigerator or freezer, make sure the appliances
are not touching each other. This is to prevent condensation from forming on the outside.
min=50mm
min=50mm
673mm
905mm
min=50mm
1900mm
1062mm
1515mm
130°
min=50mm
min=50mm
Levelling
For vibration-free operation, the appliance needs to be in a level position. To do this, adjust the
adjustable front feet to properly balance the appliance.
Doors
- Levelling and anchor the refrigerator by adjust the feet.
- Clockwise rotate feet to heighten them by hand.
- Anticlockwise rotate feet to lower them by hand.
20
21
EN
