ESI Waveterminal 192
22
5. Connection with external device - Waveterminal 192L
Caution: This chapter is for Waveterminal 192L only
Basically, Waveterminal 192L is a digital audio interface with analog 2 channel (stereo)
input, 1 Mic channel(mono) input, analog 6 channel output and Digital stereo Optical
output.
Also with optional add-on card MI/ODI/O add-on card, you can add SPDIF Optical
Input, SPDIF Coaxial In/Out and 1 In/1 Out MIDI interface.
1. Waveterminal 192L Input/Output
Waveterminal 192L consists of analog 2 channel Input, one Mic input & 6 channel
output and Digital Optical output.
Waveterminal 192L has total of 5 connectors composed of TRS(Tip/Ring/Sleeve)
connectors.
MIC input is Balanced type input. So you need to use general Balanced Mic cable.
And Line input is stereo input port, which accepts stereo input using stereo cable.
Other 3 connectors are configured as stereo output connectors. In other words, you
should use stereo cables to these connectors and you can get 6 channel analog outputs.
Basic theory of connection cable
Waveterminal 192L’s 5 analog connectors use TRS type connectors which is devided by
three connection points and called Tip(+)/Ring(-)/Sleeve(GND). This TRS used in two
different ways.
- Stereo connector: Tip(+)/Ring(-)/Sleeve(GND) are left, right and ground. Using stereo
cable, send 2channel signal. It’s Unbalanced connection.
- Balanced connector: Three parts are Hot(+), Cold(-) and GND(Ground). This is for
Mono channel.
The point is that using one cable, 2channel flows or 1 channel flows.
Waveterminal 192L’s MIC input port is mono.
And Line in/outputs are stereo.
