Details of EZ-Programming Options
12 13
Power-on Sequence
PwrOnSTD (Standard)
In this setting, each time you turn on
PASSPORT, it will display “Passport,” “SRX,”
“LASER,” “Ka-band,” “K-band,” “X-band,”
followed by a brief X-band alert. It then
confirms communications to the front
radar
receiver, and front and rear Laser
Shifters. If a communications error occurs,
the appropriate error message will be
displayed. (see page 21 for error messages)
PwrOnFST (Fast power-on)
This setting shortens PASSPORT’s start up
sequence to a single beep. PASSPORT’s self-
diagnostic test is still performed in this mode.
Signal Strength Meter
MeterSTD (Standard meter)
The meter displays the band, and bar graph
showing signal strength. (factory default)
MeterEXP (ExpertMeter)
The meter simultaneously tracks up to 2
Ka-band, 2 K-band, and 4 X-band signals.
MeterSPC (SpecDisplay)
The meter displays the actual numeric
frequency of the radar signal being received.
Note: See more details on pages 6-7.
AutoMute
aMute ON (AutoMute on)
In this setting, PASSPORT’s audio alerts will
initially be at the volume you set, but after a
few seconds, PASSPORT will automatically
reduce the volume level, to keep you
informed, but not annoyed. (factory default)
aMuteOFF (AutoMute off)
With AutoMute off, PASSPORT’s audio alerts
will remain at the volume you set for the
duration of the radar encounter.
Audio Tones
Tone STD (Standard tones)
This setting uses more pleasing tones.
(factory default)
ToneLOUD (Loud tones)
This setting uses tones that are more piercing,
and easier to hear in a louder vehicle.
Optional Voice Alerts
Voice alerts are only available using an
external speaker, which can be purchased
through your local installer.
Voice ON
In this setting, all radar and laser alerts,
including SWS messages will be
accompanied by a voice announcement.
Voice OFF
With Voice off, the standard tones will be
used.
NOTE: The program option to turn
Voice ON/OFF is only displayed when
an external speaker is plugged in.
City Mode Sensitivity
City STD (Standard)
In this setting, when you put PASSPORT in
the City mode, X-band sensitivity is
significantly reduced, to minimize
annoyances from X-band intrusion alarms
and motion sensors. (factory default)
City LoX (Low X band sensitivity)
In this setting, when you put PASSPORT in
the City mode, X-band sensitivity is reduced
more than the standard setting. This will
reduce X band alarms from other sources
even further, but also significantly reduces
range to X band traffic radar.
City NoX (No X band sensitivity)
In this setting, when you put PASSPORT in
the City mode, PASSPORT will not respond
to any X band signals. WARNING: Only
choose this setting if you are
absolutely certain that there are no
X-band traffic radar units where you
drive.
Note: These settings only apply when
PASSPORT is operated in City mode. X-band
sensitivity is not affected when used in
“Auto” or “Highway” modes.
Brightness
Brt AUTO (Auto)
Display brightness automatically adjusted
to suit the ambient lighting in your car.
(factory default)
Brt MIN (Minimum)
Sets display to minimum brightness.
Brt MED (Medium)
Sets display to medium brightness.
Brt MAX (Maximum)
Sets display to maximum brightness.
Brt DARK (Dark)
In this setting, PASSPORT will only display a
very dim HD, AD, or CD for the power-on
indication, and will not show any visual
alerts when signals are detected.
Bands
BandsALL
In this setting, all rada
r, laser (receive only),
and SWS frequencies are monitored. This is
the factory default setting, and it is highly
recommended that you use your PASSPORT
in this mode.
BandsMOD
In this setting, PASSPORT will warn you
with an audible alert, and associated text
message, that one or more bands have been
turned off in programming (i.e.”SWS OFF”).
This warning is displayed during the start-
up sequence (standard or fast).
WARNING: Only modify bands if you
are absolutely certain that there are
no traffic radar units using that
specific band in your area.
