Power Connection
To power C65, plug the small end of the
SmartCord, (telephone-type connector)
into the modular jack on C65’s right side,
and plug the lighter plug adapter into your
vehicle’s lighter socket or accessory socket.
C65 operates on 12 volts DC negative
ground only. The lighter plug provided is a
standard size and will work in most
vehicles. However, some vehicles may
require the optional European sleeve to
ensure a snug fit. If so, simply call our
service department to order one. This
sleeve slides over the SmartCord’s lighter
plug adapter. Of course, your lighter socket
must be clean and properly connected for
proper operation.
NOTE: Depending on your vehicle, the
lighter socket power may either be
continuously on, or it may be switched on
and off with your ignition switch.
Optional power cords
See the Accessories section for details on
our optional Direct-wire SmartCord.
Mounting Location
WARNING: ESCORT cannot anticipate the
many ways the C65 can be mounted.
It is important that you mount C65 where
it will not impair your view nor present a
hazard in case of an accident.
Where to mount C65
For optimum detection performance, we
recommend the following:
• Using the Windshield QuickMount,
mount your C65 level, and high enough on
your front windshield to provide a clear
view of the road from the front and rear.
• Mount C65 away from windshield
wipers, other solid objects, and heavily
tinted areas that might obstruct the radar
antenna or laser lens.
6
Installation
Windshield QuickMount
C65’s QuickMount windshield bracket is
designed for unobtrusive and hassle-free
mounting.
1 Depress the QuickMount button on
the top of C65 (by the word ESCORT) and
slide the QuickMount bracket into the slot
until it is locked into the position which
best fits the angle of your windshield
(there are four settings available). For
extremely horizontal or extremely sloped
windshields, the QuickMount bracket can
be bent.
To ensure that the suction cups adhere to
the windshield firmly, be sure to keep
both your windshield and the suction cups
clean.
2 To adjust C65 on your windshield, use
the QuickMount adjustment button
located on the top of the C65, and slide
C65 forward or backward to obtain a level
horizontal position.
When installed and adjusted properly, the
back top edge of the C65 should rest
solidly against your windshield.
Caution!
A few vehicles (including some Porsches)
have windshields with a soft anti-lacerative
coating on the inside surface. Use of
suction cups will permanently mar this
coating. Consult your dealership or the
vehicle owner’s manual to determine if
your windshield has this coating.
User’s Tip
You can leave the QuickMount bracket in
place on your windshield, and easily
remove the C65 by pressing the
adjustment button and sliding it off the
mount. Again, be sure to position the
bracket where it won’t present a hazard in
the event of an accident. Additional
mounts are available.
7
