Brightness
Brt LAST (last)
In this setting, when you turn on PASSPORT,
the display will be the last brightness you
had selected during operation with the dim
button. (factory default)
Brt MIN (minimum)
In this setting, each time you turn on
PASSPORT, the display will be at the lowest
brightness.
Brt MED (medium)
In this setting, each time you turn on
PASSPORT, the display will be at the
medium brightness.
Brt MAX (maximum)
In this setting, each time you turn on
PASSPORT, the display will be at the
maximum brightness.
Brt DARK (dark)
In this setting, each time you turn on
PASSPORT, the display will be in the dark
mode. This is recommended only when
using PASSPORT’s SmartCord so you have a
visual indication to confirm that PASSPORT
is operational.
Dark Mode
Dark STD (standard)
In this setting, when you select the dark
mode, the only display will be a very dim
HD, AD, or CD, indicating Highway-Dark,
Auto-Dark, or City-Dark). (factory default)
Dark ALL (all)
In this setting, when you select the dark
mode using the dim button, PASSPORT’s
display will be totally dark, without even
displaying any power-on indication. In this
setting, PASSPORT’s SmartCord will provide
the only visual indication to confirm that
PASSPORT is operational.
Bands
BandsDFT
In this setting all radar and laser
frequencies, (with the exception of POP
mode) are monitored. This is the factory
setting, and it is recommended that you use
your PASSPORT in this mode.
BandsMOD
In this setting, PASSPORT will warn you
with an audible alert, and associated text
message stating which band has been
modified (i.e. “X OFF”). This warning is
displayed during the start up sequence
(standard or fast).
WARNING: Only modify bands if you
are absolutely certain that there are
no traffic radar units using that
specific band in your area.
Features and Specifications
Operating Bands
• X-band 10.525 GHz ± 25 MHz
• K-band 24.150 GHz ± 100 MHz
• Ka-band 34.700 GHz ± 1300 MHz
• Laser 904nm, 33 MHz bandwidth
Radar Receiver / Detector Type
• Superheterodyne VTO
• Scanning Frequency Discriminator
• Digital Signal Processing (DSP)
Laser Detection
• Quantum Limited Video Receiver
• Multiple Laser Sensor Diodes
Display Type
• 280 LED Alphanumeric
• Bar Graph, ExpertMeter, or SpecDisplay
• 3-Level Dimming, plus Dark Mode
Power Requirement
•
12VDC, Negative Ground
• SmartCord (included)
Programmable Features
• Power-On Indication
• Power-On Sequence
• Signal Strength Meter
• AutoMute
• Audio Tones
• City Mode Sensitivity
• Display Brightness
• Dark Mode
• Radar / Laser Bands
Sensitivity Control
• AutoSensitivity, Highway and City
Auto Calibration Circuitry
SmartShield VG2 Immunity
Dimensions (Inches)
• 1.25 H x 2.85 W x 5.32 L
