5
EN
Ermenrich Ping SM100 Wire Tracker
The kit includes: transmitter with alligator clips, receiver, USB cable, earbuds, carry bag, user manual, and warranty.
Getting started
Shift the on/off-switch (7) to the ON-position to turn the transmitter on.
Shift the on/off-switch (7) to the OFF-position to turn the transmitter off.
Press and hold the power button(14) for 3seconds to turn the receiver on/off.
Turn the sensitivity adjustment knob (6) on the transmitter and the sensitivity adjustment knob (15) on the receiver clockwise
to adjust the sensitivity levels from 1 to 8.
Charging the device
The transmitter and the receiver use rechargeable lithium batteries. Connect the USB cable to the device and the DC adapter
(not included) via a USB plug and connect it to the AC power supply to charge the device.
When the battery is low, the low battery indicator will blink; immediately charge the device.
Electrical cable tracing
1. Clamp the red alligator clip to the phase wire or the positive terminal of the testing cable; and clamp the black alligator clip
to the grounding wire or to the grounding terminal of the testing cable. To trace a multicore cable, clamp the red alligator
clip to any color core of the cable and then clamp the black alligator clip to the cable shielding or clamp it to ground.
2. Press (5) to switch the transmitter to the scanning mode.
3. Turn the sensitivity adjustment knobs (6 and 15) to the maximum sensitivity.
4. Place the receiver near the cable bundle (or near the surface where the cable is hidden) and move the receiver along the
cable to trace it. When the sensor is in close proximity to the target cable, the receiver will emit a beeping sound. Todetect
the cable more accurately, lower the sensitivity. The closer the device is to the object, the louder the signal will be.
!
The maximum voltage of the circuit to be tested with the use of the alligator clips shall not exceed 220V AC.
Telephone cable tracing
1. Connect a telephone cable or a network cable to the transmitter using the telephone adapter cable (8).
2. Press (5) to switch the transmitter to the scanning mode.
3. Turn the sensitivity adjustment knob (6 and 15) to the maximum sensitivity.
4. Place the receiver near the cable bundle (or near the surface where the cable is hidden) and move the receiver along the
cable to trace it. When the sensor is in close proximity to the target cable, the receiver will emit a beeping sound. Todetect
the cable more accurately, lower the sensitivity. The closer the device is twct, the louder the signal will be.
Power cable tracing
1. Connect a power cable to the power cable socket (4) of the transmitter.
2. Press (5) to switch the transmitter to the scanning mode.
3. Turn the sensitivity adjustment knob (6 and 15) to the maximum sensitivity.
4. Place the receiver near the cable bundle (or near the surface where the cable is hidden) and move the receiver along the
cable to trace it. When the sensor is in close proximity to the target cable, the receiver will emit a beeping sound. Todetect
the cable more accurately, lower the sensitivity. The closer the device is to the object, the louder the signal will be.
!
The maximum voltage of the circuit to be tested by means of connection to the power cable socket of the transmitter shall
not exceed 400V.
!
Observe the safety precautions to avoid the risk of electric shock.
Specifications
Detectable cable types
power cables, multicore wires, coaxial cables, telephone
cables, network cables
Detection and tracing of underground and hidden wires +
Max. detection depth 2m
Anti-jamming function +
De-energized cable detection +
Live cable detection +
Max. voltage of power cables (connection with the use of
the power cable socket)
400V
Max. voltage for tested circuits (connection with the use of
alligator clips)
220V AC
Operating temperature range –10… +40°C / +14… 104°F
Power supply
transmitter: 3.7 V, 1800mA·h rechargeable lithium battery
receiver: 3.7 V, 1100mA·h rechargeable lithium battery
(5 V, 1A DC adapter)
The manufacturer reserves the right to make changes to the product range and specifications without prior notice.
Please carefully read the safety instructions and the user manual before using this product. Keep away from children. Use
the device only as specified in the user manual.
