ENGLISH
888-24-324-G-02 rev. E • 08/18
Specifi cations
Troubleshooting
Cart dimensions
30.3"W x 45.4"H x 26.1"D (77x115x66 cm)
Cart weight (without equipment)
181 lb (82 kg)
Rated weight capacity
Top Work Surface
25 lb (11.3 kg)
Device Slot Size
17.1"W x 11.2"H (43.4x28.4 cm)
Device with case and power cord installed must fi t within
these dimensions.
Max Dimensions of WAP
10"W x 10"H x 2.2"D (25.4x25.4x5.6 cm)
Max Dimensions of Switch
(Must meet 1U Rack Mount Standard)
17.5"W x 12.4"H x 1.8"D (44x26x4.4 cm)
Cooling/ventilation
Four 12V DC fans, ventilated doors and side panel
External power outlet(s)
One or two outlets, depending on region
100-120V~, 4A max, 50/60 Hz or
220-240V~, 2A max, 50/60 Hz
WAP and Switch Outlets
100/120V~, 4A max, 50/60 Hz or
220-240V~, 2A max, 50/60 Hz
Shipping dimensions
37"W x 30"D x 52"H (94x75x132 cm)
Shipping weight
227 lb (103 kg)
Power system
100-120V~,12A, 50/60Hz
Maximum input for 5 devices cannot exceed 8.5A
or
220-240V~,10A, 50/60Hz
Maximum input for 5 devices cannot exceed 4.0A
Environmental
Temperature range:
Operating 0° to 30°C (32° to 86°F)
Storage -40° to 60°C (-40° to 140°F)
Relative humidity (maximum):
Operating 10%–90% (non condensing)
Storage 5%–95% (non condensing)
Altitude (maximum): 2000 m (6,562 ft)
Certifi cation:
UL 60950 Safety of Information Technology Equipment, CAN/CSA C22
2 No. 60950; UL 1678 Household, Commercial, and Institutional-Use
Carts, Stands, and Entertainment Centers for Use with Audio and/or Video
Equipment.
ICES-003 Issue 5, Class A
FCC Part 15 Class A
RoHS and REACH compliant material used.
Noti cation Probable Cause Resolution
Blue ON/OFF switch ashing. There is an over-current condition that cannot be resolved. Power has been
removed to the devices. An over-current condition could be a defective device
installed or possibly something plugged into external auxillary outlet causing
too much current.
To correct, remove source of over-current condition,
then unplug from wall and then plug back in, or push
power switch o then back on to reset.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
CAN ICES3(A)/NMB-3(A).
Changes or modi cations not expressly approved by the Ergotron could void the user's authority to operate the equipment.
Intended for institutional use.
