Option B
For Concrete and Concrete Block Wall Installation
3/8˜ (10mm)
Concrete Drill BitHammerElectric Drill Pencil Tape Measure
1/2˜ (13mm)
Socket Wrench
• Avoid the risk of personal injury or property damage! Tighten the
lag screws only until they are pulled firmly against the wall plate
(DO NOT overtighten). Do not use a drill; only use a socket wrench.
• Use wall anchors for this mounting option.
• Mount the wall plate directly on the concrete surface.
• Minimum concrete block size: 8 x 8 x 16" (203 x 203 x 406mm)
Mark 4 Hole Positions
Tools Needed (Not Included)
WARNING:
° 8˜ (203mm)
A1
A2
Wall Anchor
A2
04
Level
35mm
2 3/8˜
60mm
1 3/8˜
35mm
60mm
1 3/8˜
35mm
1 3/8˜
35mm
02 03 04 05 06 07 08 09 10 11 12 13 14 15
16 17 18 19 20 21 22 23 24 25 26 27 28 29
30 31 32 33 34 35 36 37 38 39 40 41 42 43
