Equip® POS Thermal printer User Manual
31
from bitmap 01H. Thus the first data set [xL xH yL yH d1.... .dk] is NV bitmap
01H and the last data group [xL xH yL yH d1.... .dk] is the NV bitmap n . The total
number is the same as the number of NV bitmaps set by the FS p command.
The definition data of an NV bitmap consists of [xL xH yL yH d1.... .dk].
Therefore, when there is only one NV bitmap with n=1, the printer processes the
data set [xL xH yL yH d1.... .dk] once. The printer uses ([data: (xL+xH
*256)*(yL+yH*256)*8]+[header:4]) bytes of NV memory.
The definition area in this printer is 192K bytes (maximum). This command
can define several bitmaps, but cannot define a bitmap whose total data capacity
[bitmap data + header] exceeds 192K bytes.
Even if the ASB is set, the printer does not transmit the ASB status or perform
status detection during the processing of this command.
Once an NV bitmap is defined, it cannot be deleted by executing the ESC @
command, reset, or power down.
This command performs only the definition of the NV bitmap and does not
perform printing. Printing of the NV bitmap is performed by the FS p command.
illustrations：When xL = 64, xH = 0, yL = 96, yH = 0
