Equip® POS Thermal printer User Manual
30
(1 ≤ (yL+yH*256) ≤ 288)
0 ≤ d ≤ 255）
k = (xL+xH*256)*(yL+yH*256)*8
Data area defined by the sum total = 64K bytes
Default value
None
Supported
Models
All models
Precaution
Frequent execution of write commands may damage the NV memory.
Therefore, it is recommended that no more than 10 write operations be performed
on the NV memory in a day.
After the process of placing an image into the NV memory, the printer
performs a hardware reset operation. Therefore user-defined characters,
downstream bitmaps should be defined after completing this command. The printer
clears the
the receive and print buffers and resets to the mode that was in effect when power
was turned on. (Hardware reset interface not supported)
This command cancels all NV bitmaps that have been defined with this
command.
Mechanical operations (including initializing the print head position when the
cover is open feeding the paper with the paper feed button, etc.) cannot be
performed during the period between the start of processing of this command and
the completion of the hardware reset.
During the processing of this command, the printer is busy and stops receiving
data when writing data to the user NV memory. Therefore, data transmission,
including real-time commands, is prohibited during the execution of this command.
A NV bitmap is a bitmap defined in nonvolatile memory. Define FS p print
with FS q.
In standard mode, this command is valid only at the start of processing on a
line.
The command is valid after the 7 bytes <FS yH> of this command have
been processed normally.
When the amount of data exceeds the left-hand side capacity of the range
defined by xL, x H, yL, yH, the printer will process the range defined by xL, xH,
yL, yH outside the defined range.
It is disabled in Group I bitmaps when any parameter in xL, xH, yL, yH is
outside the defined range.
In a group of bitmaps other than the first group, when the printer encounters a
situation in which xL, xH, yL, yH is outside the defined range, processing of this
command is stopped and writing of the NV image begins. At this point, NV
bitmaps that have not yet been defined are disabled (undefined,) but any previously
defined NV bitmaps remain valid.
d indicates definition data. In data(d), a 1 bit specifies a point to be printed
and a 0 bit specifies a point not to be printed.
This command defines n as the number of NV bitmaps. The number goes up
