18
E． Boost Reconnect Charging voltage >Low Voltage Reconnect Voltage.
Lithium battery parameters
The parameters are measured in the condition of 12V/25 ºC. Please double the values in the 24V system
and quadruple the values in the 48V system.
Battery type
Voltage control parameters
LFP
Li(NiCoMn)O2
User
Over voltage disconnect voltage
15.6V
13.5V
9~17V
Charging limit voltage
14.6V
12.6V
9~17V
Over voltage reconnect voltage
14.7V
12.7V
9~17V
Equalize charging voltage
14.5V
12.5V
9~17V
Boost charging voltage
14.5V
12.5V
9~17V
Float charging voltage
13.8V
12.2V
9~17V
Boost reconnect charging voltage
13.2V
12.1V
9~17V
Low voltage reconnect voltage
12.8V
10.5V
9~17V
Under voltage warning reconnect voltage
12.8V
11.0V
9~17V
Under voltage warning voltage
12.0V
10.5V
9~17V
Low voltage disconnect voltage
11.1V
9.3V
9~17V
Discharging limit voltage
10.6V
9.3V
9~17V
The following rules must be observed when modifying the parameter values in User for a
lithium battery.
A. Over Voltage Disconnect Voltage>Over Charging Protection Voltage(Protection Circuit
Modules(BMS))+0.2V;
B. Over Voltage Disconnect Voltage>Over Voltage Reconnect Voltage＝Charging Limit Voltage ≥
Equalize Charging Voltage＝Boost Charging Voltage ≥ Float Charging Voltage>Boost Reconnect
Charging Voltage;
C. Low Voltage Reconnect Voltage > Low Voltage Disconnect Voltage ≥ Discharging Limit Voltage.
D. Under Voltage Warning Reconnect Voltage>Under Voltage Warning Voltage≥ Discharging Limit
Voltage;
E. Boost Reconnect Charging voltage> Low Voltage Reconnect Voltage;
F. Low Voltage Disconnect Voltage ≥ Over Discharging Protection Voltage (BMS)+0.2V
WARNING
The voltage parameters of a lithium battery can be set according to the lithium
battery BMS's voltage parameters.
The required accuracy of BMS shall be no higher than 0.2V. We will not assume
any responsibility for the system abnormal when the accuracy of BMS is higher
than 0.2 v.
