Je bekijkt pagina 13 van 40
9
Tracer3210AN
30A
10mm
2
/8AWG
Tracer4210AN
40A
16mm
2
/6AWG
CAUTION
The total voltage must not exceed the PV open circuit voltage when the PV modules
are connected in series. PV open circuit voltage 46V(Tracer**06AN) or
92V(Tracer**10AN) at 25℃ environment temperature.
Battery and Load Wire Size
The battery and load wire size conform to the rated current, and the reference size as below:
Model
Rated
charge
current
Rated
discharge
current
Battery wire size
Load wire size
Tracer1206AN
Tracer1210AN
10A
10A
4mm
2
/12AWG
4mm
2
/12AWG
Tracer2206AN
Tracer2210AN
20A
20A
6mm
2
/10AWG
6mm
2
/10AWG
Tracer3210AN
30A
30A
10mm
2
/8AWG
10mm
2
/8AWG
Tracer4210AN
40A
40A
16mm
2
/6AWG
16mm
2
/6AWG
CAUTION
The wire size is only for reference. Suppose there is a long distance between the
PV array and the controller or between the controller and the battery. In that
case, larger wires can be used to reduce the voltage drop and improve
performance.
The recommended wire is selected for the battery according to the conditions
that its terminals are not connected to any additional inverter.
2.4 Mounting
WARNING
Risk of explosion! Never install the controller in a sealed enclose with flooded
batteries! Do not install the controller in a confined area where battery gas
can accumulate.
Risk of electric shock! The PV array may generate a high open-circuit voltage
when wiring the PV modules. Disconnect the breaker or fast-acting fuse first,
and be careful when wiring.
The controller requires at least 150mm of clearance above and below for proper
