CAUTION
The wire size is only for reference. Suppose a long distance exists between the PV
array and the controller or between the controller and the battery. In that case,
larger wires shall be used to reduce the voltage drop and improve the system
performance.
The recommended wire for the battery is that its terminals are not connected to
any additional inverter.
2.4 Dry contact instruction
Dry contact parameter
Rated Value：5A/30VDC
Maximum Value：0.5A/60VDC
1) Control the utility/generator ON/OFF via the
(Utility/Generator) dry contact
Utility/Generator start-up Voltage (V
ON
) = Under Voltage Warning
Voltage
Utility/Generator stop Voltage (V
OFF
) = Under Voltage Warning Recover Voltage
Battery Voltage (V
BAT
)
Start-up the Utility/Generator: V
BAT
＜V
ON
.
Stop the Utility/Generator: V
BAT
＞ V
OFF
.
CAUTION
Before starting or stopping the Utility/Generator via the (Utility/Generator) dry
contact, you shall set the switch to the ON position.
The VON and VOFF can be set via the PC software. The Battery Control Voltage
Parameters refer to chapter 3.4 Setting.
2) Control the load first disconnection and second disconnection.
Battery Voltage (V
BAT
)
Under Voltage Warning Voltage (V
UVW
)
Under Voltage Warning Recover Voltage (V
UVWR
)
Low Voltage Disconnect Voltage (V
LVD
)
Low Voltage Reconnect Voltage (V
LVR
)
(Utility/Generator) dry contact OFF interface
V
BAT
≤V
UVW
: The (Utility/Generator) dry contact OFF interface controls the load ❶ first disconnection.
V
BAT
≥V
UVWR
: (Utility/Generator) dry contact OFF interface controls the load ❶ first connection.
(Load) dry contact
V
BAT
≤V
LVD
: The (Load) dry contact controls the load ❷ second disconnection.
V
BAT
≤V
LVR
: The (Load) dry contact controls the load ❷ second connection.
