19
www.solarv.de
Copyright © 2021 SolarV GmbH
BATT1
system voltage
error
①
Red Fast
flashing
Green
Fast
flashing
Battery capacity shows
empty, battery frame
blink.
Fault icon blinks and
battery frame blink
①No alarm for system voltage error when BATT1 is lithium battery.
(3)
Buttons
Press the
button
Parameters of PV array
Parameters of BATT1
Parameters of BATT2
Auto global browsing mode( )
Press the
button
Browse the parameters of PV array Browse
the parameters of BATT1
Browse the parameters of BATT2
Press the
button and
hold on 5s
Select the temperature unit
Select the battery type
(1)
Auto global browsing mode
Operation:
Press the button until is appear. Then Press the button,
appears. Now it is set as auto global browsing mode.
Loop diaplay：PV voltage →PVcurrent →PV power→Generated energy→BATT1
voltage→BATT1 current→Max. BATT1 voltage→Min.BATT1 voltage →BATT1
