②At minimum operating environment temperature.
2.3 Wire Size
The wiring and installation methods must conform to all national and local electrical code
requirements.
➢ PV Wire Size
Since PV array output can vary due to the PV module size, connection method or sunlight
angle, the minimum wire size can be calculated by the Isc＊ of PV array. Please refer to the
value of Isc in the PV module specification. When PV modules are connected in series, the Isc
is equal to Isc of PV modules. When PV modules are connected in parallel, the Isc is equal to
the sum of the PV modules’ Isc. The Isc of the PV array must not exceed the controller’s
maximum PV input current. Please refer to the table as below:
NOTE: All PV modules in a given array are assumed to be identical.
＊Isc=Short circuit current(amps) Voc= Open circuit voltage
Model
Max. PV input
current
Max. PV wire size
DR1106N-DDB/DDS
DR1206N-DDB/DDS
10A
4mm
2
/12AWG
DR2106N-DDB/DDS
DR2206N-DDB/DDS
DR2210N-DDB/DDS
20A
6mm
2
/10AWG
DR3106N-DDB/DDS
DR3206N-DDB/DDS
DR3210N-DDB/DDS
30A
10mm
2
/8AWG
CAUTION: When the PV modules connect in series, the open circuit voltage of
the PV array must not exceed 46V(DR**06N-DDB/DDS),92V (DR**10N-DDB/DDS).
➢ Battery and load wire size
The battery and load wire size must conform to the rated current, the reference size as
below:
Model
Rated Charge
Current
Battery wire size
DR1106N-DDB/DDS
DR1206N-DDB/DDS
10A
4mm
2
/12AWG
DR2106N-DDB/DDS
DR2206N-DDB/DDS
DR2210N-DDB/DDS
20A
6mm
2
/10AWG
DR3106N-DDB/DDS
DR3206N-DDB/DDS
DR3210N-DDB/DDS
30A
10mm
2
/8AWG
