3
www.solarv.de
Copyright © 2021 SolarV GmbH
❶
Mounting hole sizeΦ5mm
❻
BATT1 terminals
❷
LCD(Refer to chapter 3)
❼
BATT2 terminals
❸
Grounding Terminal
❽
RS485 Communication port
⑵
❹
Remote temperature sensor
⑴
port
❾
AES (signal) output port
⑵
❺
PV terminals
❿
Terminal protection cover
⑴The controller is charging the BATT1 as default (25℃) without temperature compensation
function when it’s not connected to the remote temperature sensor, or the temperature
sensor is damaged. The temperature compensation is ONLY designed for the lead-acid
battery, for lithium battery, there is no temperature compensation.
⑵AES port which output is 12V/200mA and RS485 Port which output is 5V/200mA are independent
of DR1106/2106/3106N models, the AES port output voltage is the battery voltage. The above two
ports of DR1206/2206/3206/2210/3210N models share the power of 5VDC/Max. 200mA
Also the AES signal port is designed for AES supporting car refrigerator, It is required for
internal power switching device.
1.4 Starter battery BATT2 Instruction
1)
Working principle of starter battery
The controller trickle charges the BATT2 at 1A constant current. When the voltage reaches the
“Full voltage” during the BATT2 charging process, the controller will stop charging and exit from
constant voltage charging mode.
2)
Voltage control parameters of starter battery
Item
Default
Modify range
Full voltage
13.8V/12V; 27.6V/24V
9～17V(24V×2)
Charge return voltage
13V/12V; 26V/24V
9～17V(24V×2)
CAUTION: Please follow the logic of Full Voltage > Return Voltage when modifying
the voltage point.
3)
Start Charging Conditions
CAUTION: BATT2 ONLY supports lead-acid battery type, before starting
the BATT2
charging, please connect the BATT1 first.
Condition1: BATT2 start charging when BATT1 reach the float charging stage and the
BATT2 voltage is lower than the “Charging Return Voltage.
Condition 2: BATT2 start charging when the batteries total charging current is higher than
3A and the BATT2 voltage is lower than the “Charging Return Voltage.
4)
Stop Charging Conditions
Condition 1: BATT2 stops charging when the PV voltage is no 2V higher than BATT1.
Condition 2: BATT2 stops charging when BATT1 is not in float charging stage and the total
charging current for the battery is less than 2.5A.
Condition 3: BATT2 stops charging when BATT2 reaches the “Full Voltage”.
