Envertech microinverter ensures top performance for its associated PV module.
The result is maximum energy production from your PV system.
2.2 Monitoring Device: EnverBridge
Once you install EnverBridge and have it connected to your broadband router
or modem, Envertech microinverters automatically begin to report to
EnverBridge’s server. EnverBridge monitoring system presents both real-time
and historical performance data.
2.3 Optimal Reliability
Microinverter systems are inherently more reliable than traditional inverters.
The distributed nature of a microinverter system ensures that there is no
single-point failure in the PV system. Envertech Microinverters are designed to
operate at full power at ambient temperatures as high as +65℃ (150 ℉). The
microinverter casing is designed for outdoor installation and complies with the
IP67 protection level.
Note: To ensure optimal reliability and to meet warranty requirements, the
microinverter must be installed according to the instructions in this manual.
2.4 Simple Design
PV systems using Envertech microinverters are very simple to design and install.
You can install a combination of PV modules of any type, at any orientation,
and in any quantity. You won’t need to install cumbersome traditional
inverters. Each microinverter can be quickly mounted on the PV rack, directly
beneath each PV module. Low-voltage DC wires connect from the PV module
directly to the co-located microinverter, eliminating the risk of personnel
exposure to dangerously high DC voltage.
3. Product Information
Note: For optimum reliability and to comply with warranty conditions, the
microinverter must be installed according to the instructions in this manual.
3.1 Major Characteristics
Envertech microinverters have the following characteristics which make
Envertech microinverters “Highly Efficient, Highly Reliable, Highly Cost
Effective”.
Low DC input voltage.
Wide MPPT voltage range ensures high yield under various weather conditions.
High MPPT accuracy ensures minimum power loss during converting.
Complete set of protective functions.
Also, the following protective functions are integrated into Envertech
microinverters. Internal overvoltage/undervoltage protection
Faulty grounding protection Grid monitoring.
Current monitoring in grounding DC monitoring.
Microinverter can be adapted to almost all modules. Before installation,
please check the parameters of the microinverters and modules to ensure that
they are compatible.
CE Statement
Envertech (Shanghai) Corporation Ltd. declares that this microinverter (Wi-Fi
integrated) complies with the essential requirements and other relevant
provisions of Directive 2014/53/EU. Following Article 10(2) and Article 10(10),
this product is allowed to be used in all EU member states.
Safe Distance Warning
Use the microinverter (Wi-Fi integrated) in an environment with a temperature
between -40°C and 65°C, The device complies with RF specifications when the
device is used at 20 cm from your body.
Operation Frequency (Only for products with built-in Wi-Fi module)
Wi-Fi: 2.4G
Frequency: 2412MHz-2472MHz
Output Power: 802.11 b/g/n:<19dBm (e.i.r.p)
Bluetooth Low Energy (Only for products with Bluetooth function)
Frequency: 2402MHz-2480MHz, Max e.i.r.p <2dBm
