9 10
Model EVT720 EVT800SE EVT800
Input Data（DC）
Recommended Module Power Range (W) (180W～500W+)*2 (180W～550W+)*2 (180W～550W+)*2
Maximum Input Voltage (V)
Minimum Start Voltage (V)
Maximum Continuous Input Current (A) 12*2 14*2 14*2
Maximum Input Short Circuit Current (A)
Number of MPPT
Output Data（AC）
Maximum Continuous Output Power (VA) 720 800 800
Maximum Continuous Output Current (A) 3.27 3.64 3.63
Nominal Output Voltage/Range (V)
Power Factor(Adjustable)
Total Harmonic Distortion
Maximum Units Per 12AWG Branch (Units) 7 6 6
Efficiency
Peak Efficiency (%)
MPPT Efficiency (%)
Nighttime Power Consumption (mW)
Features
Communication
Compliance
Inverter Isolation
Overvoltage Category
Protective Class
Warranty
Mechanical and Environment Data
Ambient Temperature Range (°C)
Relative Humidity
Dimensions (W*H*D) (mm) 264*194*35.5 248*236*27.5 264*194*35.5
Weight (kg) 4.1 2.8 4.1
Ingress Protection (IP)
Cooling
-40℃ to +65℃
0%～98%
IP 67
Natural convection
<3%
+/-0.90
96.50%
99.90%
<100
High Frequency Isolated
OVC III (AC Main), OVC II (PV)
Class I
15 Years (20 Years Optional)
Nominal Frequency/Range (Hz)
PLCC (Power Line Carrier Communication) / Wi-Fi
IEC/EN 62109-1/-2,IEC/EN 61000-3-2/-3,IEC/EN 61000-6-1/-2/-3/-4,IEC/EN
55014-1/-2, EN 50549- 1 :2019, IEC/EN 62920:2017, VDE-AR-N 4105:2018, TOR
2019,0VE R25:2020, NA/EEA-NE7-CH2022, C10/11 :2019,
UTE C15-712-1 :2013,VFR 2019, CEI 0-21 :2019, 2016/631 EU – (NC RfG)
60
16
25
2
220/230/ (189-260)
50Hz (47.5-52.5Hz)
60Hz (57.5-62.5Hz)
Model EVT1600SE EVT1800SE EVT2000SE
Input Data（DC）
Recommended Module Power Range (W)
Maximum Input Voltage (V)
Minimum Start Voltage (V)
Maximum Continuous Input Current (A)
Maximum Input Short Circuit Current (A)
Number of MPPT
Output Data（AC）
Maximum Continuous Output Power (VA)
1600 1800 2000
Maximum Continuous Output Current (A) 7.27 8.18 9.09
Nominal Output Voltage/Range (V)
Power Factor(Adjustable)
Total Harmonic Distortion
Maximum Units Per 12AWG Branch (Units)
3 2 2
Maximum Units Per 10AWG Branch (Units) 4 3 3
Efficiency
Peak Efficiency (%)
96.50% 96.30% 96.00%
MPPT Efficiency (%)
Nighttime Power Consumption (mW)
Features
Communication
Compliance
Inverter Isolation
Overvoltage Category
Protective Class
Warranty
Mechanical and Environment Data
Ambient Temperature Range (°C)
Relative Humidity
Dimensions (W*H*D) (mm)
Weight (kg)
Ingress Protection (IP)
Cooling
Nominal Frequency/Range (Hz)
50Hz (47.5-52.5Hz)
4
25
20*4
16
60
(250W～650W+)*4
<100
99.90%
<3%
+/-0.90
60Hz (57.5-62.5Hz)
15 Years (20 Years Optional)
IP 67
4.7
Natural convection
300*199.5*41
0%～98%
-40℃ to +65℃
PLCC (Power Line Carrier Communication) / Wi-Fi
IEC/EN 62109-1/-2,IEC/EN 61000-3-2/-3,IEC/EN 61000-6-1/-2/-3/-4,IEC/EN
55014-1/-2, EN 50549- 1 :2019, IEC/EN 62920:2017, VDE-AR-N 4105:2018, TOR
2019,0VE R25:2020, NA/EEA-NE7-CH2022, C10/11 :2019,
UTE C15-712-1 :2013,VFR 2019, CEI 0-21 :2019, 2016/631 EU – (NC RfG)
High Frequency Isolated
OVC III (AC Main), OVC II (PV)
Class I
220/230/ (189-260)
