S-PLAY NANO (70095)
Visit the ENTTEC website for the latest version.
..
18|
ID: 5950772
USER MANUAL
Document Updated: Dec 2023
Events
The Events page allows:
Create up to 4 custom Events, ready to be embedded in playlists.
Send Events through: Relay, UDP and OSC.
Editing, testing and deletion of Events.
Use events to allow integration between S-PLAY NANO and other devices by sending commands over
UDP and OSC protocols and interacting with the relay.
UDP
A UDP Event will send the command defined below
when activated.
Commands are limited to 1024 characters.
UDP strings ending in \r – the \r will be replaced by a
carriage return.
UDP strings ending in \n – the \n will be replaced by a
line feed.
Internal UDP event can be sent by setting IP to 127.0.0.1
and Port to 5000 (or Network Settings - UDP input port).
OSC
When activated, this Event will send the OSC data
defined in the settings.
OSC Strings, Floats and Integers can be defined.
All OSC addresses must start with a leading ‘/’ sign.
Relay
Control the relay action. When activated in a playlist the Relay
will perform the selected action.
NO: Normally Open
NC: Normally Closed
Note: On system power-up, the Relays position is set to be
normally open.
