S-PLAY LITE (70094)
Visit the ENTTEC website for the latest version.
..
USER MANUAL
18 |
ID: 5950188
Document Updated: April 2024
7. If you wish to view the output live, press the ‘Preview’ button at the top left of the interface to send
the recorded data to the fixtures of your S-PLAY LITE’s outputs as defined on the Settings page.
8. Save the cue once completed.
Note:
When setting single-channel or dimmer fixtures, choose 'All/W' for individual channel control.
Dynamic Cue
Dynamic Cues are recordings that allow DMX/Art-Net/sACN streams to be recorded and integrated into
a show. Follow the instructions below to create a dynamic cue at your preferred methods.
1. Click the green icon and choose "Dynamic" as the cue type to open the Dynamic Cue editor
window.
2. Start by assigning a name to the cue for easy identification.
3. Select one of the following options for data capture:
• DMX (up to 2 Universes)
• Art-Net (up to 16 Universes)
• sACN (up to 16 Universes)
4. Activate the Internal Universe for recording.
5. Specify the External Universe, corresponding to the universe of the external source.
6. There are 2 ways to record:
1) Manual cue recording by clicking the red "Start Rec" button.
2) Configure a Recording Trigger to precisely initiate and stop recording, enabling you to
effortlessly capture a show using a remote trigger. Select recording triggers from the options
below:
• OSC, UDP, RS232 triggers start on message received and stop when same message received
again.
