S-PLAY LITE (70094)
Visit the ENTTEC website for the latest version.
..
USER MANUAL
15 |
ID: 5950188
Document Updated: April 2024
Web Interface
The S-PLAY LITE offers easy configuration and control through a web browser on any computer within
the same Local Area Network (LAN) as the device. Users can directly type the IP address into the web
browser's URL field, whether the S-PLAY LITE is assigned a DHCP address or a Static IP address.
Top Menu
The S-PLAY LITE’s web interface consists of the following pages:
Home
The Home page which is the default landing page presents an overview of all playback activities going
on the S-PLAY LITE.
When used in combination with the lock function, the homepage can be used to as a system page for
the end users to view all custom interface and playlists:
Interfaces:
Navigate to custom interface.
Playlists
View/Set intensity for Playlists
Play and control all Playlists
View/Set progress individual Playlist
Schedules:
Activate and Pause schedules
Note: Specific interfaces, schedules,
playlists can be hidden from the home page
by selecting the ‘Hide from Home’ option on
each of their configuration pages.
Cue
S-PLAY LITE allows a maximum of 100 cues created from a combination of Static, Dynamic and Effect
Cues. The dedicated Cue page offers an array of functionalities, allowing cues to be easily configured,
duplicated, edited, and previewed before building into a playlist.
3 key types of cues that can be created by using the green icon:
Static: A lighting state of up to 16 DMX Universes. DMX data can be user-defined values or a
snapshot of the incoming DMX frame. This can be incorporated into a playlist with applied fade-
in/out times.
Dynamic: A recording of up to 16 DMX Universes of lighting control data within a specified time
frame. The S-PLAY LITE allows a perfect loop when recording over a user-defined period.
Effect: Capable of creating a gradient effect within the S-PLAY LITE without the need for a physical
DMX source or lighting design software.
