S-PLAY LITE (70094)
Visit the ENTTEC website for the latest version.
..
USER MANUAL
11 |
ID: 5950188
Document Updated: April 2024
Hardware Features
Overview
1U height – Half width
Two bi-directional 5-Pin female XLR DMX Ports
12 to 24v DC Input (8w max power draw) – Power supplies over 5A should not be connected to
the S-PLAY LITE
MicroSD card storage (Class 10 40/10 Mb/s Read/write performance/format as Linus EXT TS, ie.
EXT3 or EXT4)
100 Mbps Ethernet link featuring 802.3AF PoE
4 Digital Inputs (GPI)
2 Relay outputs (NC, NO, COM)
Solid-state design
Versatile din rail, surface and rack mounting options.
S-PLAY LITE Connectivity
Micro SD
Backup, restore files Or
Expand memory capacity.
DC Power Input
12-24 DC Jack
RS232
RS232 DB9 connector capable of
transmitting or receiving RS232
triggers
DMX In/Out
Two bi-directional DMX ports to
record, play back or trigger playlist
using DMX.
Relay Outputs
Two relay outputs to send
triggers to 3
rd
party device.
Digital Inputs
Four digital inputs to receive
triggers from buttons, switches,
pressure sensors, etc.
Ethernet (10/100MBps)
PoE Ethernet port capable of
transmitting or receiving Art-net,
sACN, OSC, UDP. +HTTP & OSC,
Device API.
Web Interface
Use the web interface to create
playlists, record cues, apply
updates and access the full
functionality of the device.
Reset/Trigger Button
Using this button to resume device
back to factory default or setup as
a trigger for playlists.
LED Indicator
Fast reference for user to
identify the device status.
