HD Standards Supported

1080i 50,59.94 or 60 Hz SMPTE 274M -4,5,6

720p 50,59.94 or 60 Hz SMPTE 296M -1,2,3

1080p 23.98,24 or 25 Hz SMPTE 274M -9,10,11

1080sF 23.98,24 or 25 Hz RP211 -14,15,16

Analog Audio Inputs

Number Eight (selectable as inputs or outputs)

Type Balanced, transformerless

Impedance >15K Ω

Maximum Input Level 24 dBu

CMRR >60 dB, 20 Hz to 10 KHz

Quantization 24 bits, 128 x Oversampled

Sample Rate 48 KHz

Reference Level -10 dBu or +4 dBu

Frequency Response +/- 0.1 dBu, 20 Hz to 20 KHz

Crosstalk <106 dB

Dynamic Rang >106 dB

Analog Audio Outputs

Number Eight (selectable as inputs or outputs)

Type Balanced, transformerless

Impedance 30 Ω

Maximum Output Level 24 dBu

Resolution 24 bits, 128 x Oversampled

Reference Level -10 dBu or +4 dBu

Frequency Response +/- 0.1 dBu, 20 Hz to 20 KHz

Crosstalk <106 dB

Dynamic Range >106 dB

Embedded Output (In Serial Output)

Group Assign Two of four groups

Channels Sixteen passed

Bit Depth 24 Bit

Optical Output:

Number One

Type HD Serial Digital 1.485 Gb/s SMPTE 274M, 292M, 296M, 297M or

SD Serial Digital 270Mb/s SMPTE 259M, 297M

Wavelength 1310 nm (non-CWDM)

(1550 non-CWDM by special order)

Power -7 dBm

Max Cable Length 20 km (For greater distances, or higher power and larger loss

budgets, please contact the factory)

Fiber Type Single Mode,

Multimode compatible with 8 dB attenuation at transmit end

Connector SC
