Mode

Indicates the output aspect ratio when upconverting the input signal.

Choices are:

• Anamorphic – original material is stretched as needed to 16:9.

• Box – Letter Box or Pillar Box is applied to the original material.

• Crop – top and bottom edges, or right and left edges are cropped off

the original material.

• Manual – Illuminates green when the output aspect ratio has been set

manually.

Bars

Illuminates green when color bars are selected as the output signal.

Graticule

Illuminates green when the on-screen aspect ratio graticule is displayed.

Gain

Illuminates green when video gain is set to unity, or red when set to other

than unity.

Pwr (Power)

Illuminates green when power is applied to the unit and the internal

voltage regulator is functioning correctly.

ADJUSTING PARAMETERS FROM THE FRONT PANEL

Use the Mode, Right Arrow, and Left Arrow buttons to select and adjust

parameters from the front panel.

Pressing the Mode button activates the front panel for editing and tabs between

each section of editable parameters.

Pressing the Right Arrow or Left Arrow advances the selection within a given

section of parameters, or increases (Right Arrow) or decreases (Left Arrow) the

value of a selected parameter.

The LED of an edited parameter will blink for 15 seconds, after which time its value is

stored in memory. If power is interrupted before this 15 second timeout period has

elapsed, the edited state will not be not saved.
