BrightEye 90-A HD Up/Down/Cross Converter and ARC with Analog Audio
BrightEye 90-A - Page 22
Aud Input
The appearance of this menu will depend on the mode selected and the type of
audio used.
Multiplexer Mode
When the module is set for Mux 8, the Input menu provides the controls
shown below:
• Group A Status – the status of the audio selected in
Group A Select will be displayed as No Audio Present,
Group 1 OK, Group 2 OK, Group 3 OK, or Group 4 OK.
• Group B Status – the status of the audio selected in
Group B Select will be displayed as Off, No Audio Present,
Group 1 OK, Group 2 OK, Group 3 OK, or Group 4 OK.
• Group A Select – select the audio group to multiplex from Group 1,
Group 2, Group 3, Group 4.
• Group B Select – select the audio group to multiplex from Group 1,
Group 2, Group 3, Group 4, or Off.
When the module is set for Mux 4, the Input menu provides the controls
shown below:
• Group A Status – the status of the audio selected in
Group A Select will be displayed as No Audio Present,
Group 1 OK, Group 2 OK, Group 3 OK, or Group 4 OK.
• Group A Select – select the audio group to multiplex from Group 1,
Group 2, Group 3, Group 4.
Demultiplexer Mode
When the module is set for Demux, the Input menu provides the controls
shown below.
• Group A Status – the status of the audio selected in
Group A Select will be displayed as No Audio Present,
Group 1 OK, Group 2 OK, Group 3 OK, or Group 4 OK.
• Group B Status – the status of the audio selected in
Group B Select will be displayed as Off, No Audio Present,
Group 1 OK, Group 2 OK, Group 3 OK, or Group 4 OK.
• Group A Select – select the audio group to demultiplex from
Group 1, Group 2, Group 3, Group 4.
• Group B Select – select the audio group to demultiplex from
Group 1, Group 2, Group 3, Group 4, or Off.
See Audio Input diagram on next page
NOTE:
