www.ensembledesigns.com BrightEye 83 and 83-F - Page 12

83 and 83-F

HDMI to 3G/HD/SD SDI Converters

Input Menu

• Input – This menu provides a read-only status indication of input video presence. The video

format coming in on the HDMI connector is auto detected and reported here. BrightEye 83

and 83-F support all of the 3G, HD and SD standards listed in the chart below.

3G HD SD Other

3G 1080p/50 720p/50 SD 525 No Input

3G 1080p/59.94 720p/59.94 SD 625 Unknown

3G 1080p/60 720p/60

1080i/50

1080i/59.94

1080i/60

1080p/25

1080p/23.98

1080p/24

1080sF/25

1080sF/23.98

1080sF/24

• Unknown – If the status indicator displays “Unknown“, the unit is detecting an invalid or

incompatible input signal. Possible reasons for this are:

1. The incoming signal is HDCP encrypted (see note below for an explanation of HDCP)

2. The incoming signal is an unsupported format, such as a computer resolution of 1024 x 768

3. The incoming signal is an unsupported refresh rate

Note: HDCP (High-bandwidth Digital Content Protection) is a content encryption system

for HDMI. It is meant to prevent copyright content from being copied. Protected content,

like a movie on a Blu-Ray disc is encrypted by its creator. Devices that want to display the

protected content, like a television, must have an authorized key in order to decode the

signal and display it. The entity that controls the HDCP standard strictly limits the kinds of

devices that are allowed decryption keys. Devices that decrypt the content and provide an

unencrypted copy are not allowed.

• No Input – If the status indicator displays “No Input”, the BrightEye is not detecting any input

signal. Check your cabling connections:

Note: In this situation none of the Input LEDs on the front panel will be illuminated, and the

Power LED will be illuminated.
