SPECIFICATIONS

Analog Video Input

Number One

Signal Type HD or SD: Y, Pr, Pb (SMPTE or Beta levels)

HD or SD: Analog Component RGB (sync on green)

Analog Composite PAL or NTSC

Analog S-Video PAL or NTSC

Impedance 75 1

Return Loss > 40 dB

Input DC +/- 1 volt DC

Input Hum < 100 mV

Analog Audio Inputs

Number Two

Type Balanced

Impedance > 15K 1

Maximum Input Level 24 dBu

CMRR > 60 dB, 20 Hz to 10 kHz

Quantization 24 bits, 128x oversampled

Sample Rate 48 kHz

Reference Level -10 dBu or + 4 dBu

Frequency Response ± 0.1 dB, 20 Hz to 20 kHz

Crosstalk < 106 dB

Dynamic Range > 106 dB

Optical Output

Number One

Type SD and ASI

(SMPTE 297M, optical equivalent of 259M)

HD (SMPTE 274M, 292M or 296M)

Wavelength 1310 nm (non-CWDM)

(1550 non-CWDM by special order)

Power -7 dBm

Max Cable Length 20 km (For greater distances, or higher power and larger loss

budgets, please contact the factory)

Fiber Type Single Mode

Multi-mode compatible with 8 dB attenuation at transmit end

Connector SC

Analog Video to SDI Performance

Bit Resolution 14-bit input quantization, 4x oversampling

Decoding Fully adaptive comb filter

K Factors > 1%

Signal to Noise > 64 dB weighted

Freq Response ± 0.1 dB, 0 to 5.5 MHz in SD

±0.1 dB, 0 to 12 MHz; ±0.5 dB, 12 to 30 MHz in HD
