BrightEye 20 Analog and Digital Audio Embedder or Disembedder
BrightEye-12
SPECIFICATIONS
AES/EBU Digital Inputs:
Number: Two (Total of four channels, selectable as inputs or outputs)
Type: AES3id
Connectorization: Coaxial, 75 Ω
Bit Depth: 20 and 24 bit
Sample Rate: 30 kHz to 100 kHz (Sample Rate Converted internally to 48 kHz)
Reference Level: -18 or -10 dBFS (selectable)
AC-3, Dolby-E: Supported when inputs are synchronous
AES/EBU Digital Outputs:
Number: Two (Total of four channels)
(selectable as inputs or outputs)
Type: AES3id
Connectorization: Coaxial, 75 Ω
Bit Depth: 20 and 24 bit
Sample Rate: 48kHz (Synchronous to video output)
Reference Level: -18 or -10 dBFS (selectable)
Video Input:
Number: One
Signal Type: 270Mb/s SD Serial Digital
(SMPTE 259M)
Impedance: 75 Ω
Return Loss: > 15 dB
Max. Cable Length: 300 meters
Video Output:
Number: One
Signal Type: 270Mb/s SD Serial Digital
(SMPTE 259M)
Impedance: 75 Ω BNC
Return Loss: >15 dB
Output DC: None (AC Coupled)
Analog Audio Inputs:
Number: Four
(selectable as inputs or outputs)
Type: Balanced
Impedance: >15K Ω
Max. Input Level: 24 dBu
CMRR: >60 dB, 20 Hz to 10 kHz
Quantization: 24 bits, 128x Oversampling
Sample Rate: 48 kHz
Reference Level: -10 dBu or +4 dBu
Frequency Response: ±0.1 dB, 20 Hz to 20 kHz
Crosstalk: <102 dB
Dynamic Range: >106 dB
