Je bekijkt pagina 12 van 20
BrightEye 11-HD HD/SD SDI to Analog Converter
SPECIFICATIONS
Serial Digital Input:
Number: One
Signal Type: HD Serial Digital 1.485 Gb/s
SMPTE 274M or 296M
or SD Serial Digital 270 Mb/s SMPTE 259M-C
Impedance: 75 Ω
Return Loss: > 15 dB
Max Cable Length 100 Meters for HD; 300 meters for SD (Belden 1694A or equiv.)
Analog Output:
Number: One component or one composite and one Y/C
Type: Beta/SMPTE, Y, Pr, Pb
RGB
NTSC. PAL Composite
NTSC, PAL S-Video
Return Loss: > 40 dB
Output DC: None (AC coupled)
Serial Digital Output:
Number: One
Type: Follows input
Impedance: 75 Ω
Return Loss: > 15 dB
Max Cable Length 100 Meters for HD (Belden 1694A or equivalent)
SDI to Analog Performance:
Bit Resolution: 12 bit output reconstruction
8 X oversampling
Signal to Noise: > 65 dB
Frequency Response: ± 0.1 dB , 0 to 5.5 MHz
K Factors: < 1%
ScH Phase Error: < ± 2 degrees
Differential Phase: < 1 degree
Differential Gain: < 1%
General Specifications:
Size: 5.625” W x 0.8 “ H x 5.5” D
(143 mm x 20 mm x 140 mm) including connectors
Power: 12 volts, 7 watts
(100-230 VAC modular power supply not included)
Temperature Range: 0 to 40 degrees C ambient
Relative Humidity: 0 to 95% noncondensing
Due to ongoing product development, all specifications are subject to change.
