BrightEye 10 Optical/SDI to Analog/SDI Converter
BrightEye-12
SPECIFICATIONS
Serial Digital Input:
Number: One
Signal Type: 270 Mb/s SD Serial digital (SMPTE 259M)
Impedance: 75 Ω
Return Loss: > 15 dB
Max Cable Length 300 meters
Optical Input:
Number: One
Type: SD
(SMPTE 297M Optical equivalent of 259M)
Wavelength: 1310 nm
Sensitivity: –18 dBm
Maximum Length: 20 km
Fiber Type: Single Mode
Multi-mode compatible with 8 dB atttenuation at transmit end
Connectro: SC
Analog Output:
Number: One
Type: Beta/SMPTE, Y, Pr, Pb,
RGB
NTSC. PAL Composite
NTSC, PAL S-Video
Return Loss: > 40 dB
Output DC: None (AC coupled)
Serial Digital Output:
Number: One
Type: 270 Mb/s SD Serial Digital
(SMPTE 259M)
Impedance: 75 Ω BNC
Return Loss: > 15 dB
Output DC: < 50 mV
SDI to Analog Performance:
Bit Resolution: 12 bit output reconstruction
8 X oversampling
Signal to Noise: > 65 dB
Frequency Response: ± 0.1 dB , 0 to 5.5 MHz
K Factors: < 1%
ScH Phase Error: < ± 2 degrees
Differential Phase: < 1 degree
Differential Gain: < 1%
