and knowledge only if they are supervised or instructed in the
safe use of the product and understand the risks that may occur.
Instruction manual:
Adjustable pulse power supply N3110 is designed for powering appli-
ances operating under DC voltage and maximum current of 600 mA
and input power of 7.2 W.
The power supply can be used for devices with the stated current and
input power values on their label up to a maximum of 600 mA (7.2 W).
The output voltage of the pulse power supply is stabilised – the voltage
value is kept at the set level regardless of the load.
Technical specications:
Input voltage, frequency and
current:
100–240 V~; 50/60 Hz; 0.35 A
Output voltage:
3 V / 4.5 V / 5 V / 6 V / 7.5 V /
9 V / 12 V (+/-6 %)
Max. output current: 600 mA (7.2 W)
Cable length: ca 1.5 m
Power consumption without
load:
<0.5 W
Operating temperature: 0~40 °C
Dimensions: 36 × 66 × 30 mm
Exchangeable power connectors:
B 3.5/15; C 3.0× 1.0/10;
D 5.0× 2.1/12; G 5.5× 2.5/10;
H 3.5× 1.35/10; I 4× 1.7/10;
S 2.35× 0.75/8.7
Connection procedure:
1. Current and input power – check the appliance‘s label to make
sure it uses the appropriate current and input power in mA and W.
The value must be lower or equal to 600 mA and 7.2 W.
2. Output voltage can be adjusted – use the turn switch to set the
desired voltage based on the appliance. The turn switch is located
