6. Specifications
Device Type :
Housing&Mounting : 72mm x 72mm x 95.5mm DIN Size 43700 plastic housing
for panel mounting. Panel cut-out is 69x69mm.
Protection Class : NEMA 4X (IP65 at front, IP20 at rear).
Weight : Approximately 0.16Kg.
Environmental Rating : Standard, indoor at an altitude of less than 2000 meters
with none-condensing humidity.
oooo
Storage / Operating Temperature: -40 C to +85 C / 0 C to +50 C
Storage / Operating Humidity : 90 % max. (None condensing)
Installation : Fixed Ýnstallation
Overvoltage Category : II.
Pollution Degree : II. Office or workplace, none conductive pollution
Operating Conditions : Continuous
Supply Voltage and Power 50/60 Hz. 2VA
24V V 50/60 Hz. 2VA
Analogue Output : 0/2...10V (Max.10mA) or
0/4...20mA
Analogue Output Accuracy : ± % 0.1
Display : 14 mm Red 4 digits LED Display
LED : Start(Red), Forward Direction(Red),
Reverse Direction (Red), Error(Red), P(Red) 3 mm Led
Control Panel For V/F Speed Controller
100-240 V V (-%15;+%10)
(-%15;+%10)
24VZ(-%15;+%10) 2W
Electrical Specification of Digital
Input :Max. Permissible Voltage 30VZ
Min. High Level 7VZ
Max. Low Level 5VZ
Electrical Specification of Digital
Outputs :Max. Permissible Voltage 30VZ
Max. Output Current 5mA@30VZ
Min. High Level 7VZ
Max. Low Level 5VZ
Z
Z
7. Other Informations
Manufacturer Information:
Emko Elektronik Sanayi ve Ticaret A.Þ.
Demirtaþ Organize Sanayi Bölgesi Karanfil Sk. No:6 16369
BURSA/TURKEY
Phone : +90 224 261 1900
Fax : +90 224 261 1912
Repair and Maintenance Service Information:
Emko Elektronik Sanayi ve Ticaret A.Þ.
Demirtaþ Organize Sanayi Bölgesi Karanfil Sk. No:6 16369
BURSA/TURKEY
Phone : +90 224 261 1900
Fax : +90 224 261 1912
Thank you very much for your preference to use Emko Elektronik
Products.
Your Technology Partner
www.emkoelektronik.com.tr
37
