26 Installation - ENGLISH
Option 1, mount from the top
1. Place the installation template on the surface where the product is to be installed. Mark the holes for drilling using
the attached template and a pencil.
NOTE! Place the installation template so that the front panel of the cooker hood will not be rubbing against the
cabinet cover when the sliding set moves.
2. For installations without carbon filter, drill the flue outlet hole.
3. Drill holes with 4mm diameter on the points marked as A, B, C, D.
