14

SDI OUT SOURCE

Sets the source signal of the SDI output.

• SDI In (default): Routes the SDI input signal to the SDI Out 1

and SDI Out 2 outputs.

• HDMI In: Routes the HDMI input signal to SDI Out 1 and SDI

Out 2.

• Scaler: Routes the scaler’s output signal to SDI Out 1 and SDI

Out 2.

If Scaler is selected, see

Scaler Source

below, and

Output

Format

in the Video Menu.

SCALER SOURCE

Sets the input video signal that’s routed to the scaler.

• SDI In (default): Routes the SDI input signal to the scaler.

• HDMI In: Routes the HDMI input signal to the scaler.

SDI OUT 1&2

• Loop Out: SDI Out 1 and SDI Out 2 output two different

signals. SDI Out 1 becomes an active loop output of the SDI

input signal. SDI Out 2 will output the signal selected in SDI

Out Source.

• Output (default): Sends the input signal or the scaler signal

to both SDI Out 1 and SDI Out 2.
