6 Description
Remote Control Remo KNX RF • Version: 14.09.2021 • Technical changes and errors excepted.
1.1. Deliverables
• Wireless remote control with integrated battery
• USB cable 0.5 m (USB-A plug to USB-B micro plug)
1.2. Technical specifications
The product is compliant with the provisions of EC guidelines.
1.3. Notes on wireless equipment
When planning facilities with devices that communicate via radio, adequate radio reception
must be guaranteed. The range will be limited by legal regulation and structural circum-
stances. Avoid sources of interference and obstacles between receiver and transmitter, that
could disturb the wireless communication. Those would be for example:
• Walls and ceilings (especially concrete and solar protection glazing).
• Metal surfaces next to the wireless participants (e. g. aluminium construction of a
conservatory).
• Other wireless devices and powerful local transmitters (e.g. wireless headphones),
which transmit on the same frequency. Please maintain a minimum distance of 30
cm between wireless transmitters for that reason.
1.4. General notes
The device is only to be used for the intended purpose described in this manual. Any im-
proper modification or failure to follow the operating instructions voids any and all warran-
ty and guarantee claims.
After unpacking the device, check it immediately for possible mechanical damage. If it has
been damaged in transport, inform the supplier immediately.
Housing Plastic
Colour black
Degree of protection IP 40
Dimensions approx. 64 x 122 x 11 (B x H x T, mm)
Display colour TFT, capacitive, dimmable,
resolution 320 x 480 Pixel
Weight approx. 100 g
Ambient temperature operating 0…50 °C, storage -10…+60 °C
Ambient humidity 5...95 % RH, avoid condensation
Operating voltage integrated battery 3.8 V DC
Wireless frequency 868.2 MHz
Channels 32
Data output KNX RF (S-Mode)
Group addresses max. 512
Assignments max. 1024
Communication objects 417
