78 Commissioning
Control System KNX WS1000 Style • Version: 28.05.2018 • Technical changes and errors excepted.
5.1. Procedure
Installation, testing, commissioning and fault repair should only
be carried out by a qualified electrician.
To install the control unit, proceed as follows:
• Installation
• Commissioning
• Basic setting in the ETS and in the menu System > Installation
• Automatic settings in the menu System > Automatic Settings
This chapter describes the commissioning of the device. Prior to commissioning all
components must be installed (fitted and with their cables connected). Read through
the notes and instructions carefully.
5.1.1. Start control unit
ICondensation water can occur if a device is taken from a cold
into a warm room. Before the commissioning of the control take
care that there is no humidity inside the device
(let dry if necessary).
After installation, connecting cables to the unit and checking all connections, switch
the power supply on.
The control unit starts and in the display the model and serial number appear initially.
Then the following will be shown
• “Read drive parameter OK“
(or if there is an error: “Error initialising drive parameter with factory settings.”)
• “Wireless interface”
(or if there is an error: “Wireless interface error”)
• “Wireless channel initialised OK“
(or if there is an error: “Wireless channel initialisation error”)
After successfully running through the initial test sequence, the control unit will be in
the starting position with a display of weather data. Weather data is displayed if the
control system is receiving data (brightness, sun direction and height, precipitation,
wind, temperature, and indoor room data). The weather animation is only shown when
there no error messages are displayed.
