75 Installation
Control System KNX WS1000 Style • Version: 28.05.2018 • Technical changes and errors excepted.
When motors are connected in parallel at RF-MSGs, take note of whether a group con-
trol relay is prescribed by the manufacturer. Group control relays can be obtained from
Elsner Elektronik or the motor manufacturer. Only drives with the same function (only
windows, only awnings, only blinds, only shutters) can be brought together in groups.
If motors are connected in parallel which are unsuitable for this
purpose, both they and the control unit will be damaged.
For D.C. drives we offer appropriate power supply units. In case of need we ask for de-
tails of the motor type, the manufacturer and – if available – the technical data.
Tips on connecting windows
With windows the supply of fresh air can be very well regulated using the Step window
configuration. In this, the control unit checks the room temperature every 3 minutes. If
the temperature is close to the reference value, the window will be opened or closed
step by step. You can adjust the number of steps in the Automation menu (“Number
of steps” button).
For sliding roofs, during normal operation of ventilators, it is not necessary to use the
full stroke. For that reason you can adjust the size of the opening in the Automatic
menu (“Movement position” button). If the sliding roof should be opened fully, this
can take place manually.
ATTENTION
Material damage due to use of step/sliding roof operation with
inappropriate window motors!
Not all window motors are suitable for step/sliding mode.
•Use this functions only with motors that are qualified for step/sliding
operation by the manufacturer.
