48 Parameter setting
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
8.14. VOC PI-control
If you activate air quality control, you can use the following settings to define control
type, setpoint values, and ventilation.
General control
The Sensor KNX VOC/TH-UP Touch can be used to control one or two-stage venti-
lation.
Configure a block for the ventilation control using the blocking object.
Specify when the current control variables are to be sent to the bus. Periodic sending
is safer, in case a message does not reach a recipient. You may also set up periodic
monitoring using an actuator with this setting.
The status object shows the current status of the output variable (0 = OFF, >0 = ON) and
can for example be used for visualisation.
Switching output sends on change to 1 • Do not send message
• if switching output = 1 send 1
Switching output sends on change to 0 • Do not send message
• if switching output = 0 send 0
Switching output sends on change and
periodically
Send switching output status
Switching output sends on change to 1
and periodically
if switching output = 1 send 1
Switching output sends on change to 0
and periodically
if switching output = 0 send 0
Use control Yes • No
Type of control • One-stage ventilation
• Two-stage ventilation
Behaviour of the blocking object with value • 1 = block control | 0 = release control
• 0 = block control | 1 = release control
Blocking object value
before first communication
0 • 1
Send control variable • on change
• on change and periodically
at and above change of (in ppm) 1...20; 2
Cycle
(if sent periodically)
5 s • ... • 5 min • … • 2 h
