40 Parameter setting
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
for the initial start-up, as the factory settings are always used until the first communi-
cation (setting via objects is ignored).
During initial commissioning, a setpoint value must be defined which is valid until
the first communication of a new setpoint value. For units which have already been tak-
en into service, the last communicated setpoint value can be used. Basically, an air hu-
midity range is specified in which the setpoint value can be changed (object value
limit).
Enter, how the setpoint value will be received from the bus. Basically, a new value can
be received, or simply a command to increase or decrease.
A set setpoint value will be retained until a new value or a change is transferred. The
current value is saved, so that it is retained in the event of a power supply failure and
will be available once the power supply is restored.
Setpoint value setting using parameter:
Set the threshold values and hysteresis directly.
Setpoint value setting using communication object:
In "Humidification and dehumidification" control mode, a dead zone is specified so that
a direct changeover switching between humidification and dehumidification can be
avoided.
Humidification starts, when the relative air humidity is lower or equal to the setpoint
value - dead zone value.
Setpoint value setting using Parameter • Communication objects
Setpoint value in 0.1% RH
(valid until 1st communication)
0 … 100; 70
Setpoint value setting using Parameter • Communication objects
The value communicated last shall be
maintained
• never
• after power supply restoration
• after power supply restoration and
programming
Start setpoint in %
valid until first communication
(not upon saving the setpoint value after
programming)
0 … 100; 50
0…100; 40
Object value limit (min.) in % 0…100; 60
Object value limit (max.) in % Absolutwert • Anhebung / Absenkung
1,00% • 2,00% • 5,00% • 10,00%
Dead zone between humidification and
dehumidification in %
(only if both humidification and dehumidifi-
cation are used)
0…50; 15
