49 Parameter setting

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

Controller setpoint

The setpoint values can be set directly in the application program using parameters, or

be defined via the bus using a communication object.

Setpoint value setting using parameters:

Set the setpoint value directly.

Setpoint value setting via communication object:

Enter, how the setpoint value will be received from the bus. Basically, a new value can

be received, or simply a command to increase or decrease.

During initial commissioning, a setpoint value must be defined which is valid until the

first communication of a new setpoint value. For units which have already been taken

into service, the last communicated setpoint value can be used. Basically, an air humid-

ity range is given in which the setpoint value can be changed (object value limit).

A set setpoint value will be retained until a new value or a change is transferred. The

current value is saved, so that it is retained in the event of a power supply failure and

will be available once the power supply is restored.

Send status object(s) • on change

• on change to 1

• on change to 0

• on change and periodically

• on change to 1 and periodically

• on change to 0 and periodically

Cycle

(if sent periodically)

5 s • 10 s • … • 2 h

Specified setpoint using Parameter • Communication objects

Target value in ppm 300…5000; 800

Threshold value setting using Parameter • Communication objects

The last communicated value should be

retained

• never

• after power supply restoration

• after power supply restoration and

programming

Start setpoint value in ppm

valid until first communication

(not upon saving the setpoint value after

programming)

300… 5000; 800

Object value limit (min) in ppm 300…5000; 400

Object value limit (max) in ppm 300…5000; 1500

Type of threshold value change Absolute value • Increase/decrease

Increment in ppm

(upon increase/decrease change)

1 • 2 • 5 • ... • 20 • ... • 100 • 200
