Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

Dehumidification and/or humidification

Depending on the control mode, settings sections for humidification and dehumidifi-

cation appear (level 1/2).

For dual-level dehumidification, the setpoint value difference between the two levels

must be defined, i.e. the setpoint value which, when exceeded, triggers the switch to

the 2nd level.

Determine the deviation from the setpoint value at which the maximum variable value

is reached, i.e. the point at which maximum output is used.

The reset time shows how quickly the controller responds to deviations from the set-

point value. In case of a short reset time, the control responds with a fast increase of

the control variable. In case of a long reset time, the control responds somewhat less

urgently and needs longer until the necessary control variable for the setpoint value

deviation is reached.

You should set the time appropriate for the humidification/dehumidification system at

this point (note manufacturer instructions).

Now specify, what should be sent when the control is blocked.

On release, the control variable follows the rule again.

8.9. Dewpoint measurement

The Sensor KNX VOC/TH-UP Touch calculates the dewpoint temperature and can

output the value to the bus.

Target value difference between level 1

and 2 in %

(for level 2 only)

0...50; 15

Maximum control variable is reached

at target/actual difference of %

1...50; 5

Reset time in minutes 1...255; 3

When blocked, the control variable shall • not be sent

• send a specific value

Value in %

(if a value is sent)

0...100

Use dewpoint temperature No • Yes

Sending pattern • never

• periodically

• on change

• on change and periodically

At and above change of

(if sent on change)

0,1°C • 0,2°C • 0,5°C • 1,0°C • 2,0°C • 5,0°C

Send cycle

(if sent periodically)

5 s • 10 s • 30 s • 1 min • … • 2 h
