36 Parameter setting

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

The unit can calculate a mixed value from its own reading and an external value. Set

the mixed value calculation if desired. If an external portion is used, all of the following

settings (threshold values, etc.) are related to the overall reading.

The minimum and maximum readings can be saved and sent to the bus. Use the

„Reset humidity min/max value“ object to reset the values to the current readings. The

values are not retained after a reset.

8.7. Humidity threshold values

Activate the required air humidity threshold values. The menus for setting the thresh-

old values are displayed.

8.7.1. Threshold value 1, 2

Threshold value

Set, in which cases threshold values and delay times received via objects are to be

retained. The parameter is only taken into consideration if the setting via object is ac-

tivated below. Please note that the setting "After power supply restoration and pro-

gramming" should not be used for the initial start-up, as the factory settings are always

used until the first communication (setting via objects is ignored).

Set the threshold value directly in the application program using parameters, or define

them via the bus using a communication object.

Threshold value setting using parameter:

Set the threshold values and hysteresis directly.

Use external measured value No • Yes

Ext. Reading proportion of the total reading 5% • 10% • ... • 50% • ... • 100%

All of the following settings are referred to the total value.

Send internal and total reading • never

• periodically

• on change

• on change and periodically

At and above change of

(if sent on change)

0.1% RH • 0.2% RH • 0.5% RH • 1.0% RH • ...

• 25% RH

Send cycle

(if sent periodically)

5 s • 10 s • ... • 2 h

Use minimum and maximum value No • Yes

Use threshold value 1/2 Yes • No

Threshold value setting using Parameter • Communication objects

Threshold value in 0.1% RH

(valid until 1st communication)

0 … 100; 70
