32 Parameter setting

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

PI control with control parameters:

This setting allows individual input of the parameters for PI control.

Specify the deviation from the setpoint value at which the maximum control variable

value is reached, i.e. the point at which maximum heating power is activated.

The reset time shows how quickly the controller responds to deviations from the set-

point value. In case of a short reset time, the control responds with a fast increase of

the control variable. In case of a long reset time, the control responds somewhat less

urgently and needs longer until the necessary control variable for the setpoint value

deviation is reached.

You should set the time appropriate to the heating system at this point (observe man-

ufacturer's instructions).

Now specify what should be sent when the control is blocked. Set a value greater 0

(=OFF) to receive a basic heating level, e.g. for floor heating.

On release, the control variable follows the rule again.

In case of a common control variable for heating and cooling, 0 is always transmitted

as a fixed value.

PI control with predetermined application:

This setting provides fixed parameters for frequent applications.

Control variable is a

(for level 2 with 2-point controlling, no

common control variables)

• 1 bit object

• 8 bit object

Control type • PI control

Setting of the controller by • Controller parameter

• specified applications

Maximum control variable is reached

at setpoint/actual difference of (in °C)

1...5

Reset time (in min.) 1...255; 30

When blocked, the control variable shall • not be sent

• send a specific value

Value (in %)

(if a value is sent)

0...100

Control type • PI control

Setting of the controller by • Controller parameter

• specified applications

Application • Warm water heating

• Floor heating

• Convection unit

• Electric heating

Maximum control variable is reached

at setpoint/actual difference of (in °C)

Warm water heating: 5

Floor heating: 5

Convection unit: 4

Electric heating: 4
